CLOUD ROUTER SWITCH CRS320-8P-8B-4S+RM

Specifications
Details
Product code CRS320-8P-8B-4S+RM
Architecture ARM 32bit
CPU 98DX226S
CPU core count 2
CPU nominal frequency 800 MHz
Switch chip model 98DX226S
RouterOS license 5
Operating System RouterOS v7
Size of RAM 256 MB
Storage size 32 MB
Storage type FLASH
MTBF Approximately 200’000 hours at 25C
Tested ambient temperature -10°C to 50°C
Suggested price $489.00
Powering
Details
Number of AC inputs 1
AC input range 100-240
Number of PSU slots 2
Frequency (Hz) 50-60
Max power consumption 600W (1150W with additional PSU)
Max power consumption without attachments 36 W
Cooling type 3 fans
PoE-out
Details
PoE-out ports Ether1-Ether8 (af/at), Ether9-Ether16 (bt)
PoE out 802.3af/at/bt
Max out per port output (input 30-57 V) 560 (af/at) / 1667 (bt) mA
Max total out (A) 17.82 A
Total output current 17.82
Total output power 963
Ethernet
Details
10/100/1000 Ethernet ports 17
Number of 1G Ethernet ports with PoE-out 16
Fiber
Details
SFP+ ports 4
Peripherals
Details
Serial console port RJ45
Other
Details
CPU temperature monitor Yes
PCB temperature monitor Yes
Voltage Monitor Yes
Certification & Approvals
Details
Certification CE, EAC, ROHS
IP 20
