Specifications
Details
Product code CRS310-1G-5S-4S+IN
Architecture ARM 32bit
CPU 98DX226S
CPU core count 1
CPU nominal frequency 800 MHz
Switch chip model 98DX226S
Dimensions 200 x 166 x 44 mm
RouterOS license 5
Operating System RouterOS v7 / SwitchOS
Size of RAM 256 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 200’000 hours at 25C
Tested ambient temperature -40°C to 70°C
Suggested price $199.00
Powering
Details
Number of DC inputs 2 (PoE-IN, DC jack)
DC jack input Voltage 18-57 V
Max power consumption 20 W
Max power consumption without attachments 8 W
Cooling type 1 fan
PoE in 802.3af/at
PoE in input Voltage 18-57 V
Ethernet
Details
10/100/1000 Ethernet ports 1
Fiber
Details
SFP ports 5
SFP+ ports 4
Peripherals
Details
Serial console port RJ45
Other
Details
CPU temperature monitor Yes
PCB temperature monitor Yes
Voltage Monitor Yes
Certification & Approvals
Details
Certification CE, EAC, ROHS
IP 20
